- 產品介紹
- 產品參數
產品規格
型號
尺寸
入射角
波長
OCM-L12-0
φ12.7x3
0°
260-270,397-405,473-488,515-532,633-660,780-810,850-915,1028-1080,1525-1575
OCM-L20-0
φ20x5
0°
260-270,351-355,397-405,473-488,515-532,633-660,780-810,850-915,1028-1080,1525-1575
OCM-L25-0
φ25.4x6.35
0°
260-270,351-355,397-405,473-488,515-532,633-660,780-810,850-915,1028-1080,1525-1575
OCM-L51-0
φ50.8x6.35
0°
260-270,351-355,397-405,473-488,515-532,633-660,780-810,850-915,1028-1080,1525-1575
OCM-L12-45
φ12.7x3
45°
260-270,397-405,473-488,515-532,633-660,780-810,850-915,1028-1080,1525-1575
OCM-L20-45
φ20x5
45°
260-270,351-355,397-405,473-488,515-532,633-660,780-810,850-915,1028-1080,1525-1575
OCM-L25-45
φ25.4x6.35
45°
260-270,351-355,397-405,473-488,515-532,633-660,780-810,850-915,1028-1080,1525-1575
OCM-L51-45
φ50.8x6.35
45°
260-270,351-355,397-405,473-488,515-532,633-660,780-810,850-915,1028-1080,1525-1575
注：訂貨型號需在型號后加波長值，即：型號-波長。
